| Suggest Connecting Cable |
| No. |
Diagram |
Model No. |
Category |
Rated Voltage
(V) |
Description |
Application |
PDF |
| 1 |
 |
C6110034133
(SP1902-1P) |
Twisted Speaker Cable |
30 |
20AWG., 0.6mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
 |
| 2 |
|
C6110032133
(SP-1902-1P(V2)) |
Twisted Speaker Cable |
30 |
19AWG., 0.65mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 3 |
|
C6110035133
(SP1903-1P) |
Twisted Speaker Cable |
30 |
16AWG., 1.35mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 4 |
|
C6110064133
(SP704-1P/PVC) |
Twisted Speaker Cable |
30 |
18AWG., 0.88mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 5 |
|
C6110045133
(SP5025-1P) |
Twisted Speaker Cable |
30 |
14AWG., 2.5mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 6 |
|
C6110072133
(SP8477-1P) |
Twisted Speaker Cable |
30 |
12AWG., 3.2mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 7 |
 |
C6110067133
(SP-8442) |
Twisted Speaker Cable |
300 |
22AWG., 0.35mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 8 |
|
C6110068133
(SP-8205) |
Twisted Speaker Cable |
300 |
20AWG., 0.56mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 9 |
 |
C6110046133
(SP2402-1P) |
Twisted Speaker Cable |
300 |
19AWG., 0.75mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 10 |
|
C6110069133
(SP-8461) |
Twisted Speaker Cable |
300 |
18AWG., 0.85mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 11 |
|
C6110070133
(SP-8471) |
Twisted Speaker Cable |
300 |
16AWG., 1.3mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 12 |
|
C6110047133
(SP4802-1P) |
Twisted Speaker Cable |
300 |
16AWG., 1.5mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 13 |
|
C6110071133
(SP-8473) |
Twisted Speaker Cable |
300 |
14AWG., 2.1mmsq. Stranded TACW, Twisted Pair, PVC Insulation, PVC Sheath (Grey) |
For the connecting wiring between the amplifier & speaker |
|
| 14 |
 |
C61200181FF
(SP-CR40) |
Parallel Type Speaker Cable |
300 |
20AWG., 0.5mmsq. Stranded PACW & TACW, 2 Cores, Parallel Construction, PVC Insulation (Transparent) |
For the connecting wiring between the amplifier & speaker |
|
| 15 |
|
C61200171FF
(SP-CR70) |
Parallel Type Speaker Cable |
300 |
19AWG., 0.8mmsq. Stranded PACW & TACW, 2 Cores, Parallel Construction, PVC Insulation (Transparent) |
For the connecting wiring between the amplifier & speaker |
|
| 16 |
|
C61200391FF
(SP-CR120) |
Parallel Type Speaker Cable |
300 |
16AWG., 1.5mmsq. Stranded PACW & TACW, 2 Cores, Parallel Construction, PVC Insulation (Transparent) |
For the connecting wiring between the amplifier & speaker |
|
| 17 |
|
C61200161FF
(SP-CR240) |
Parallel Type Speaker Cable |
300 |
13AWG., 2.7mmsq. Stranded PACW & TACW, 2 Cores, Parallel Construction, PVC Insulation (Transparent) |
For the connecting wiring between the amplifier & speaker |
|
| 18 |
 |
C6120020141
(SP-RB3012) |
Parallel Type Speaker Cable |
300 |
22AWG., 0.34mmsq. Stranded PACW, 2 Cores, Parallel Construction, PVC Insulation (Red/Black) |
For the connecting wiring between the amplifier & speaker |
|
| 19 |
|
C6120021141
(SP-RB4012) |
Parallel Type Speaker Cable |
300 |
20AWG., 0.5mmsq. Stranded PACW, 2 Cores, Parallel Construction, PVC Insulation (Red/Black) |
For the connecting wiring between the amplifier & speaker |
|
| 20 |
|
C6120022141
(SP-RB7012) |
Parallel Type Speaker Cable |
300 |
19AWG., 0.8mmsq. Stranded PACW, 2 Cores, Parallel Construction, PVC Insulation (Red/Black) |
For the connecting wiring between the amplifier & speaker |
|
| 21 |
 |
C6110031322
(SP19021HT/LS) |
Fire Resistance Twisted Speaker Cable |
300 |
19AWG., 0.65mmsq. Stranded TACW, Mica Tape, Twisted Pair, LSHF Insulation, LSHF Sheath (Whiter) |
For the connecting wiring between the amplifier & speaker |
|
| 22 |
 |
C6110037311
(SP3202HT/LS) |
Fire Resistance Twisted Speaker Cable |
300 |
18AWG., 1.0mmsq. Stranded TACW, Mica Tape, Twisted Pair, LSHF Insulation, LSHF Sheath (Black) |
For the connecting wiring between the amplifier & speaker |
|
| 23 |
 |
C6110038311
(SP3025HT/LS) |
Fire Resistance Twisted Speaker Cable |
300 |
16AWG., 1.5mmsq. Stranded TACW, Mica Tape, Twisted Pair, LSHF Insulation, Al. Polyester Tape Overall Screen, 20AWG., 0.5mmsq. Stranded TACW Drain Wire, LSHF Sheath (Black) |
For the connecting wiring between the amplifier & speaker |
|
| 24 |
 |
C6210010311
(MC1616/2C/LS) |
Fire Retardant Microphone Cable |
300 |
22AWG., 0.32mmsq. Stranded TACW, 2 Cores, PVC Insulation, Cotton Yarn, Cotton Tape, TACW Braiding 75% Coverage, LSHF Sheath (Black) |
For the connection between microphone and amplifier |
|
| 25 |
 |
C6110063311
(MC3025/2C/LS) |
Fire Retardant Microphone Cable |
300 |
16AWG., 1.5mmsq. Stranded TACW, 2 Cores, LSHF Insulation, Al. Foil Overall Screen, TACW Braiding 85% Coverage, LSHF Sheath (Black) |
For the connection between microphone and amplifier |
|
| 26 |
 |
C11100101MM
(CAT.5E) |
Category 5 Enhance Lan Cable |
300 |
24AWG., 0.2mmsq. Solid PACW, 4 Pairs, Polyethylene Insulation, PVC Sheath. (Light Grey) |
For high speed data transmission |
|
| 27 |
 |
C6220020111 |
RCA Audio Video Cable |
300 |
27AWG., 0.12mmsq. Stranded PACW, 2 Cores, PVC Insulation, PACW Spiral Shield, PVC Sheath (Black) |
For audio device connection |
|
| 28 |
 |
C6220024111 |
RCA Audio Video Cable |
300 |
27AWG., 0.12mmsq. Stranded PACW, 3 Cores, PVC Insulation, PACW Spiral Shield, PVC Sheath (Black) |
For audio device connection |
|
| 29 |
 |
C1330149311 |
EIA-RS232 Fire Retardant Control Cable |
300 |
24AWG., 0.22mmsq. Stranded TACW, 3 Twisted Pairs, PE Insulation, Al. Foil Overall Screen, 24AWG., 0.22mmsq. Stranded TACW Drain Wire, TACW Braiding 90% Coverage, LSHF Sheath (Black) |
For the interconnection of control equipment and computer |
|
|
